EA Processor Card
EA processor board is based on VIRTEX 5 FX series FPGA which contains 2 PowerPC blocks PPC1 AND PPC2.PPC1 is interfaced with all the peripherals (FLASH, ETHERNET, SRAM, DDR2 SDRAM, RS422 and RS232) and PPC2 is the core processor. The Micro Blaze, as a soft-core processor, is implemented entirely in the general-purpose memory and logic fabric of Xilinx FPGA and is used to interface all the memory and communication interfaces.
Features:
| FPGA | VIrtex-5 XC5VFX130T-1FF1738I |
| Memory | 2GB of SDRAM memory with 32-bit data bus width 32MB of Flash memory with 32-bit data bus width 256MB of DDR2 memory with 32 bit data bus width |
| Communication Interfaces | Two links Fast Ethernet 10 / 100 MBPs 48 differential lines of RS422 Receivers 24 differential lines of RS422 Drivers 10 links of RS232 Transceivers |
| I/O | 48 LVTTL/TTL lines |
| Other Interfaces | JTAG port for programming FPGA |
| Dimensions | 150 mm x 50 mm x 40 mm |
| Environmental | ESS & QT Qualified as per MILSTD 810E |
