Receiver Processor LRU SARANG


The Receiver processor LRU contains 10-slot space inside, consisting of 6 boards in total andtwopower distribution modules. The back plane of RP LRU is custom designed with VPX connectorterminations. The details of six boards and Power Supply Module are given below and will bevertically loaded to the back plane

Features:
8 Slot Customized VPX Back Plane
Forced Air Cooled Chassis
3 Slot Root Complex Routing
Inter-board SRIO interface
Inter-board PCIe Interface
10 Port LAN Card Interface
Front Panel MIL-D38999 Series-III Connectors
System Consumes 500Watts ,Input Voltage is 28V DC
Total Weight including all modules <25kg
Qualification: EMI/EMC MIL-STD-416E
Temperature: -40℃ to +85℃

Radar Signal Processing
